Lenze E94AYCEO - Manual (Page 98)

Lenze · E94AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 12/2013 · TD17
98
13 Parameter reference
13.2 Parameters of the communication module for slot MXI1
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13858
C13861
C13862
Parameter | Name:
C13858 | Ethernet Port Statistics
Data type: UNSIGNED_32
Index: 10717 = 0x29DD
Display of statistical values for the data transfer via the Ethernet connections
Subcodes
Info
C13858/1 Ethernet port X233: RX
C13858/2 Ethernet port X233: RX CRC error
C13858/3 Ethernet port X233: RX rejected
C13858/4 Ethernet port X233: TX
C13858/5 Ethernet port X233: TX rejected
C13858/6 Ethernet port X234: RX
C13858/7 Ethernet port X234: RX CRC error
C13858/8 Ethernet port X234: RX rejected
C13858/9 Ethernet port X234: TX
C13858/10 Ethernet port X234: TX rejected
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13861 | CIP Module Status
Data type: UNSIGNED_16
Index: 10714 = 0x29DA
Display of the current CIP module status
(Instance attribute 8 (State) in the Identity Object (1 / 0x01) ( 121) )
• The status is also indicated via the MS LED.
 CIP™ status displays ( 78)
Selection list
(read only)
0 Nonexistent
1 Device Self Testing
2 Standby
3 Operational
4 Major Recoverable Fault
5 Major Unrecoverable Fault
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13862 | CIP Network Status
Data type: UNSIGNED_16
Index: 10713 = 0x29D9
Display of the current CIP network status
• The status is also indicated via the NS LED.
 CIP™ status displays ( 78)
Selection list (read only)
0 No IP Address
1 Nonexistent
2 Established
3 Timed Out
4 Duplicate IP
5 Self-Test
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
