14

Implemented CIP™ objects

14.1

General CIP objects

121

Lenze · E94AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 12/2013 · TD17

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

14.1

General CIP objects

14.1.1

Identity Object (1 / 0x01)

The "Identity Object" provides the identification and general information about the device.

Class attributes

Instance attributes

1) The status is set if the pending, status determining device error displays the fault, trouble, quick stop by trouble, warning

locked, or warning response.

2) The status is set if the pending, status determining device error displays the system fault response.

Attribute

ID

Service

Name

Data type

Value

1

Get

Revision

UINT

1 (0x0001)

2

Get

Max. Instance

UINT

1 (0x0001)

3

Get

Number of Instances

UINT

1 (0x0001)

6

Get

Max. ID Number Class

Attributes

UINT

7 (0x0007)

7

Get

Max. ID Number Instance

Attributes

UINT

10 (0x000A)

Attribute

ID

Service

Name

Data type

Value

1

Get

Vendor ID

UINT

587 (0x024B)

2

Get

Device Type

UINT

43 (0x002B)

3

Get

Product Code

UINT

9400 (0x24B8)

4

Get

Revision:

STRUCT of:

Firmware revision of the device

Major Revision

USINT

Minor Revision

USINT

5

Get

Status

WORD

Current device status (status bits)

Instance attribute "Status" (attribute 5)

( 122)

EtherNet/IP state diagram ( 50)

6

Get

Serial Number

UDINT

Serial number of the device

7

Get

Product Name

SHORT_STRING

E94AYCEO

8

Get

State

USINT

Current device state:

• 0: Nonexistent

• 1: Device self-testing

• 2: Standby

• 3: Operational

• 4: Major Recoverable Fault

1)

• 5: Major Unrecoverable Fault

2)

• 6 ... 254: Reserved

• 255: Standard for "Get_Attributes_All"

service

(See also

C13861

/

C14861

,

LED status

displays ( 76)

)
