14 Implemented CIP™ objects
14.2 EtherNet/IP objects
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Instance attribute "Configuration Capability" (attribute 2)
6 AcdStatus Display of the status of address conflict detection (ACD):
• 0: No address conflict detected
• 1: Address conflict detected
7 ... 31 - Reserved (0)
Bits Name Description
0 BOOTP Client The state ’1’ indicates that BOOTP is used for the TCP/IP configuration of
the device.
1 DNS Client Is not supported (state ’0’).
2 DHCP Client The state ’1’ indicates that DHCP is used for the TCP/IP configuration of
the device.
3 DHCP-DNS Update Is not supported (state ’0’).
4 Configuration Settable The state ’1’ indicates that the TCP/IP configuration can be set in
attribute 5 (Interface Configuration).
5 Hardware Configurable Is not supported (state ’0’).
6 Interface Configuration
Change Requires Reset
The state ’1’ indicates that changes of the TCP/IP configuration in
attribute 5 (Interface Configuration) will only take effect after a reset of
the device ("power off/on" or "type 0 reset").
The state ’0’ is not supported (changes becoming effective immediately).
7 AcdCapable The state ’1’ indicates that the device is provided with address conflict
detection (ACD).
8 ... 31 - Reserved (0)
Bits Name Description
