6 Commissioning
6.3 Setting the IP configuration of the Servo Drive 9400
37
Lenze · E94AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 12/2013 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
6.3 Setting the IP configuration of the Servo Drive 9400
The IP configuration is required for addressing the Servo Drive 9400 to ensure that communication
between the PC/»Engineer« or the scanner and the drive can be effected via EtherNet/IP. For this,
an IP address, subnet mask, and gateway address must be allocated. You have the following options
to select the IP parameters for the Servo Drive 9400:
• Setting via the EtherNet/IP configurator of the »Engineer« ( 38)
• Setting via codes in the »Engineer« ( 40)
• Setting via a BOOTP/DHCP server ( 42)
• Setting via the TCP/IP Interface Object (0xF5) ( 42)

Note!
• The assignment of invalid combinations of IP address, subnet mask, and gateway
address can have the consequence that no connection to the EtherNet/IP network can
be established.
• Codes C13010 / C14010 (IP address), C13011 / C14011 (subnet mask), C13012 /
C14012 (gateway address), and C13016 / C14016 (multicast IP address) show the IP
parameters currently used.
• In the case of impermissible settings, the error message EtherNet/IP: Invalid IP
parameters [0x00c86533] ( 84) is output.
