Lenze E94AYCEO - Manual (Page 139)

14 Implemented CIP™ objects
14.3 Lenze objects
139
Lenze · E94AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 12/2013 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
14.3 Lenze objects
14.3.1 Lenze Class (101 / 0x65)
The "Lenze Class (101 / 0x65)" enables the access to the error responses to EtherNet/IP errors
adjustable in code C13880 / C14880 .
Class attributes
Instance attributes
Attribute
ID
Service Name Data type Value
1 Get Revision UINT 2 (0x0002)
2 Get Max. Instance UINT 1 (0x0001)
Attribute
ID
Service Name Data type Value
1 Get No. of supported Attributes USINT 6 (0x0006)
2 Get Attribute List USINT 1 (0x0001) ... 6 (0x0006)
3 Get / Set Reaction on Idle Mode USINT Corresponds to the value in C13880/1 /
C14880/1 :
• 0 = no response
• 1 = error
• 3 = quick stop by trouble
• 4 = warning locked
• 6 = information
4 Get / Set Reaction on Fault Mode USINT Corresponds to the value in C13880/2 /
C14880/2 :
• 0 = no response
• 1 = error
• 3 = quick stop by trouble
• 4 = warning locked
• 6 = information
5 Get / Set Reaction on Expl. Msg. TO USINT Corresponds to the value in C13880/3 /
C14880/3 :
• 0 = no response
• 1 = error
• 3 = quick stop by trouble
• 4 = warning locked
• 6 = information
6 Get / Set Reaction on I/O Timeout USINT Corresponds to the value in C13880/4 /
C14880/4 :
• 0 = no response
• 1 = error
• 3 = quick stop by trouble
• 4 = warning locked
• 6 = information
