13 Parameter reference
13.3 Parameters of the communication module for slot MXI2
105
Lenze · E94AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 12/2013 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C14010
C14011
C14012
Parameter | Name:
C14010 | Active IP address
Data type: UNSIGNED_8
Index: 10565 = 0x2945
Display of the active IP address
(Instance attribute 5 (IP Address) in the TCP/IP Interface Object (245 / 0xF5) ( 132) )
Display range (min. value | unit | max. value)
0 255
Subcodes Info
C14010/1 Active IP address (most significant byte)
C14010/2 Active IP Address
C14010/3 Active IP Address
C14010/4 Active IP address (least significant byte)
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14011 | Active subnetwork mask
Data type: UNSIGNED_8
Index: 10564 = 0x2944
Display of the active subnetwork mask
(Instance attribute 5 (IP Network Mask) in the TCP/IP Interface Object (245 / 0xF5) ( 132) )
Display range (min. value | unit | max. value)
0 255
Subcodes Info
C14011/1 Active subnet mask (most significant byte)
C14011/2 Active Subnetwork Mask
C14011/3 Active Subnetwork Mask
C14011/4 Active subnet mask (least significant byte)
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14012 | Active gateway address
Data type: UNSIGNED_8
Index: 10563 = 0x2943
Display of the active gateway address
(Instance attribute 5 (Gateway Address) in the TCP/IP Interface Object (245 / 0xF5) ( 132) )
Display range (min. value | unit | max. value)
0 255
Subcodes Info
C14012/1 Active gateway address (most significant byte)
C14012/2 Active gateway address
C14012/3 Active gateway address
C14012/4 Active gateway address (least significant byte)
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
