13 Parameter reference
13.3 Parameters of the communication module for slot MXI2
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C14863
C14870
Parameter | Name:
C14863 | Ethernet Port
Data type: UNSIGNED_16
Index: 9712 = 0x25F0
Display of the baud rate currently used on the Ethernet connections
Selection list
(read only)
0 Nonexistent
1 10 Mbps/Half Duplex
2 10 Mbps/Full Duplex
3 100 Mbps/Half Duplex
4 100 Mbps/Full Duplex
5 Reserved
6 Reserved
Subcodes Info
C14863/1 Ethernet port X233 link state
C14863/2 Ethernet port X234 link state
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14870 | CIP Connections State
Data type: UNSIGNED_16
Index: 9705 = 0x25E9
Display of the current CIP connection status
Selection list
(read only)
0 Nonexistent
3 Established
4 Timed Out
Subcodes Info
C14870/1 Status of CIP connection 1
... ...
C14870/8 Status of CIP connection 8
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
