13.3 Parameters of the communication module for slot MXI2
This chapter lists the parameters of the E94AYCEO communication module (EtherNet/IP) for slot
MXI2 of the Servo Drive 9400 in numerically ascending order.
C14000
C14001
C14002
Parameter | Name:
C14000 | IP address
Data type: UNSIGNED_8
Index: 10575 = 0x294F
Setting of the IP address
 Setting the IP configuration of the Servo Drive 9400 ( 37)
Setting range (min. value | unit | max. value)
0 255
Subcodes Lenze setting Info
C14000/1 192 IP address (most significant byte)
C14000/2 168 IP address
C14000/3 124 IP address
C14000/4 16 IP address (least significant byte)
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14001 | Subnetwork mask
Data type: UNSIGNED_8
Index: 10574 = 0x294E
Setting of the subnet mask
 Setting the IP configuration of the Servo Drive 9400 ( 37)
Setting range (min. value | unit | max. value)
0 255
Subcodes Lenze setting Info
C14001/1 255 Subnet mask (most significant byte)
C14001/2 255 Subnet mask
C14001/3 255 Subnet mask
C14001/4 0 Subnet mask (least significant byte)
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14002 | Gateway address
Data type: UNSIGNED_8
Index: 10573 = 0x294D
Setting of the gateway address
 Setting the IP configuration of the Servo Drive 9400 ( 37)
Setting range
(min. value | unit | max. value)
0 255
Subcodes Lenze setting Info
C14002/1 0 Gateway address (most significant byte)
C14002/2 0 Gateway address
C14002/3 0 Gateway address
C14002/4 0 Gateway address (least significant byte)
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
