13 Parameter reference
13.2 Parameters of the communication module for slot MXI1
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13010
C13011
C13012
Parameter | Name:
C13010 | Active IP Address
Data type: UNSIGNED_8
Index: 11565 = 0x2D2D
Display of the active IP address
(Instance attribute 5 (IP Address) in the TCP/IP Interface Object (245 / 0xF5) ( 132) )
Display range (min. value | unit | max. value)
0 255
Subcodes Info
C13010/1 Active IP address (most significant byte)
C13010/2 Active IP Address
C13010/3 Active IP Address
C13010/4 Active IP address (least significant byte)
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13011 | Active Subnetwork Mask
Data type: UNSIGNED_8
Index: 11564 = 0x2D2C
Display of the active subnetwork mask
(Instance attribute 5 (IP Network Mask) in the TCP/IP Interface Object (245 / 0xF5) ( 132) )
Display range (min. value | unit | max. value)
0 255
Subcodes Info
C13011/1 Active subnet mask (most significant byte)
C13011/2 Active Subnetwork Mask
C13011/3 Active Subnetwork Mask
C13011/4 Active subnet mask (least significant byte)
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13012 | Active Gateway Address
Data type: UNSIGNED_8
Index: 11563 = 0x2D2B
Display of the active gateway address
(Instance attribute 5 (Gateway Address) in the TCP/IP Interface Object (245 / 0xF5) ( 132) )
Display range (min. value | unit | max. value)
0 255
Subcodes Info
C13012/1 Active gateway address (most significant byte)
C13012/2 Active gateway address
C13012/3 Active gateway address
C13012/4 Active gateway address (least significant byte)
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
