13 Parameter reference
13.2 Parameters of the communication module for slot MXI1
91
Lenze · E94AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 12/2013 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13003
C13005
C13006
Parameter | Name:
C13003 | MAC ID
Data type: OCTET_STRING
Index: 11572 = 0x2D34
Display of the MAC-ID
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13005 | IP configuration reference
Data type: UNSIGNED_8
Index: 11570 = 0x2D32
Selection how the IP configuration is to be effected.
(Instance attribute 3 (Configuration Control) in the TCP/IP Interface Object (245 / 0xF5) ( 132) )
 Setting the IP configuration of the Servo Drive 9400 ( 37)
Selection list (Lenze setting printed in bold) Info
0 Use stored IP The IP configuration currently saved in the
communication module is used.
1 Use BOOTP The IP configuration is assigned by the scanner using
BOOTP.
2 Use DHCP The IP configuration is assigned by the scanner using
DHCP.
The assignment of a gateway address which is not in the
same subnetwork than the IP address, is rejected.
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13006 | Multicast IP Start Address
Data type: UNSIGNED_8
Index: 11569 = 0x2D31
Setting of the multicast IP address
 Setting the IP configuration of the Servo Drive 9400 ( 37)
Setting range (min. value | unit | max. value)
0 255
Subcodes Lenze setting Info
C13006/1 239 Multicast IP start address (most significant byte)
C13006/2 64 Multicast IP start address
C13006/3 2 Multicast IP start address
C13006/4 224 Multicast start address (least significant byte)
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
