Lenze · E94AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 12/2013 · TD17

52

8

I/O data transfer (implicit messages)

8.1

Technology applications (TA) / drive profiles

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

8.1

Technology applications (TA) / drive profiles

The Servo Drive 9400 is provided with different drive profiles. They define a standardised or

individual control and status word assignment as well as the standardisation of setpoint and actual

value scalings.
The Servo Drive 9400 supports Lenze technology applications and user-definable parameter sets.

8.1.1

Lenze technology applications / user-definable parameter sets

The technology applications integrated in the drive provide the main signal flow for realising a

general or specific drive solution.
In order to use the Lenze technology applications, the following assembly object instances must be

used in the host (scanner):

See also

Assembly Object (4 / 0x04)

( 124)

.

The custom assemblies also allow for a user-definable parameter setting, depending on the

application. Hence, 32 data words (64 bytes) can freely be assigned in the »Engineer« with variables

of the port modules.
The user-definable parameter setting can be used in addition to the previously set technology

application.

I/O configuration in the »Engineer«

( 55)

Tip!
Here you will find information on configuring with the »RSLogix 5000« programming

software from Rockwell:

I/O configuration with »RSLogix 5000« version 19 or lower

( 58)

I/O configuration with »RSLogix 5000« version 20 or higher

( 63)

Instance ID

Assembly object instance

[dec]

[hex]

110

0x6E

Custom Output

(from the adapter to the scanner)

111

0x6F

Custom Input

(from the adapter to the scanner)
