13 Parameter reference
13.2 Parameters of the communication module for slot MXI1
95
Lenze · E94AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 12/2013 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13022
C13840
C13841
Parameter | Name:
C13022 | Quality of Service (DSCP)
Data type: UNSIGNED_8
Index: 11553 = 0x2D21
Setting for the prioritisation of the data packets to be transferred using Differentiated Services Codepoints (DSCP)
Setting range
(min. value | unit | max. value)
0 63
Subcodes Lenze setting Info
C13022/1 59 Reserved
C13022/2 47 Reserved
C13022/3 55 Reserved
C13022/4 47 QoS DSCP Scheduled
(Instance attribute 5 (DSCP Scheduled) in the Quality of
Service (QoS) Object (72 / 0x48) ( 130) )
C13022/5 43 QoS DSCP High Prio
(Instance attribute 6 (DSCP High Prio) in the Quality of
Service (QoS) Object (72 / 0x48) ( 130) )
C13022/6 31 Reserved
C13022/7 27 QoS DSCP Explicit Msg
(Instance attribute 8 (DSCP Explicit Msg.) in the Quality of
Service (QoS) Object (72 / 0x48) ( 130) )
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13840 | DLR Network Topology
Data type: UNSIGNED_8
Index: 10735 = 0x29EF
Display of the used DLR network topology (Device Level Ring)
(Instance attribute 1 (Network Topology) in the Device Level Ring (DLR) Object (71 / 0x47) ( 128) )
Selection list (read only)
0 Linear
1 Ring
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13841 | DLR Network Status
Data type: UNSIGNED_8
Index: 10734 = 0x29EE
Display of the DLR network status (Device Level Ring)
(Instance attribute 2 (Network Status) in the Device Level Ring (DLR) Object (71 / 0x47) ( 128) )
Selection list (read only)
0 Normal
1 Ring Fault
2 Unexpected Loop detected
3 Partial network fault
4 Rapid fault/restore cycle
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
