Lenze · E94AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 12/2013 · TD17
114
13 Parameter reference
13.3 Parameters of the communication module for slot MXI2
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C14874
C14875
C14880
Parameter | Name:
C14874 | CIP Connections Timeout Time
Data type: UNSIGNED_32
Index: 9701 = 0x25E5
Display of the timeouts (ms) of the CIP connections
Display range
(min. value | unit | max. value)
0 ms 4294967295
Subcodes Info
C14874/1 Timeout time of CIP connection 1
... ...
C14874/8 Timeout time of CIP connection 8
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14875 | CIP Connections RUN/IDLE Flag
Data type: UNSIGNED_16
Index: 9700 = 0x25E4
Display of the run and idle flags of the CIP connections
Selection list
(read only)
0 Nonexistent
1 IDLE
2 RUN
Subcodes Info
C14875/1 RUN/IDLE flag - CIP connection 1
... ...
C14875/8 RUN/IDLE flag - CIP connection 8
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14880 | Reaction on communication fault
Data type: UNSIGNED_8
Index: 9695 = 0x25DF
Setting of the monitoring response in the event of a Fault with regard to EtherNet/IP communication ( 74)
(Mapping of the Lenze object Lenze Class (101 / 0x65) ( 139) )
A change in the monitoring response becomes immediately effective.
Selection list
0 No response
1 Fault
3 Quick stop by trouble
4 Warning Locked
6 Information
Subcodes Lenze setting Info
C13880/1 0: No Response Idle Mode
C13880/2 0: No Response Fault Mode
(only for "exclusive owner" connections)
C13880/3 0: No Response Expl. message timeout
C13880/4 0: No Response Overall Ethernet communication timeout
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
