Echo ACP Configuration Manual

Change Admin Passcode

New Passcode:

****

Verify New:

****

Accept Changes

Default Access Level

Admin
User
Login Always Required

Restricted Access

1 Login
2 Change Admin Passcode
3 Change User Passcode

4 Default Access:

Admin

Restricted Access

1 Login

2 Change Admin Passcode

3 Change User Passcode
4 Default Access:

Admin

Enter Login Code

****

(enter to accept)

(back to cancel)

Restricted Access

1 Login

2 Change Admin Passcode
3 Change User Passcode
4 Default Access:

Admin

Note:

View / Clear Errors

Dimmer Errors

Overtemp: Dim 13

Rack Communication

Failure!

DMX input Inactive

All current

system errors are listed

in order of severity. Errors
automatically clear when the

condition no longer exists.

Some errors cannot be

cleared manually.

1 Save Rack Configs
2 Save Dimming Config
3 Load Dimming Config
4 Save Arch Config
5 Load Arch Config

6 Restore Defaults

7 Update Firmware

File Operations

1 Save Rack Configs
2 Save Dimming Config
3 Load Dimming Config
4 Save Arch Config

5 Load Arch Config

6 Restore Defaults
7 Update Firmware

File Operations

1 Save Rack Configs
2 Save Dimming Config
3 Load Dimming Config

4 Save Arch Config

5 Load Arch Config
6 Restore Defaults
7 Update Firmware

File Operations

1 Save Rack Configs
2 Save Dimming Config
3 Load Dimming Config
4 Save Arch Config
5 Load Arch Config
6 Restore Defaults

7 Update Firmware

File Operations

Note:

USB:\folder

<...>

EACP_fw_1.0.1.efw
EACP_fw_1.1.1.efw

Update Firmware

Load from SD Media

Load from USB Media

Update Firmware

This operation causes

the controller to

reboot.

Do you want to

Continue?

YES

Restore Defaults

Select settings

to delete:

Arch (E-ACP)

Dimming (DRd)

ALL

This operation erases

all memories (excluding

removable media) and

returns the selected

setting to factory

defaults.

Load Arch Config

SD:\folder

<...>

Unison1
Unison5
Unison9
Unison11

Only the

available removable media

display for selection. <...>

navigates to the root folder

of the removable media. All

folders are indicated

in brackets.

Load Arch Config

Load from SD Media

Load from USB Media

Only the

available removable media

display for selection.

Filename for save defaults to

the name of the currently

running configuration

file.

Unison1

Unison2
Unison3
Unison4
Unison5
Unison6
Unison7

Save Filename

Save Arch Config

Name:

Unison1

Save to SD Media
Save to USB Media

Help

Press any button for
a description of how
it’s used.

Press and hold Help
for 2 seconds
for ETC contact info.

At any time, press
Help again to exit.

Press the shortcut button

to directly access the

Dimming Control menu.

Press twice to access

the Arch Control

menu.

Press the

“Help/0” button to open

the Help dialog. Press and

hold the “Help/0” button for

2 seconds to display

ETC contact

info.

help

Note:

Select Space

from the available

list, then select the

associated Preset for

activation, deactivation,

or recording and

setting of preset fade

timing.

Note:

Record up to

six steps using

snapshot. Fade time

is the transition time

used fade to the next step

from previous levels.

Edit Step

Step:

1 of 6

Fade Time:

2 sec

Hold Time:

3 sec

Record
Insert Step After
Delete Step

Preset 10 Active

Space:

Preset 15 Active

Preset #:

Activate
Record
Fade Time:0 min 2 sec

Sequence Inactive

Space: 1
Sequence Inactive
Start:
Seq Mode:

Single

Edit Steps

Arch Control

1 Presets

2 Sequence

Arch Control

1 Presets

2 Sequence

Note:

Dimming Control

1 Set Levels

2 Dimmer Check
3 Release Set Levels

Set Levels

2: -

3: -

4: -

5: -

6: -

7: -

8: -

9: -

10:- 11:- 12:-
13:- 14:- 15:-
16:- 17:- 18:-
19:- 20:- 21:-

Dimming Control

1 Set Levels

2 Dimmer Check

3 Release Set Levels

Dimmer Check

Dimmer Number:

Level:

Next Dimmer
Previous Dimmer

Release Set Levels

All Set Levels

control has been

released

Dimming Control

1 Set Levels
2 Dimmer Check

3 Release Set Levels

A level entry of 100%

(full) is displayed as “FL”.

Dimmer check controls

are released when exiting
“Dimmer Check” operation.

A
A

1 About
2 Dimming Setup
3 Arch Setup
4 Dimming Control
5 Arch Control
6 File Operations

7 View/Clear Errors

8 Restricted Access

1 About
2 Dimming Setup
3 Arch Setup
4 Dimming Control
5 Arch Control
6 File Operations
7 View/Clear Errors

8 Restricted Access

1 About
2 Dimming Setup
3 Arch Setup
4 Dimming Control
5 Arch Control

6 File Operations

7 View/Clear Errors
8 Restricted Access

Main Menu
