Version info, Space combine, Version info space combine – ETC Echo Architectural Control Processor (ACP) v1.0.0 User Manual
Page 31: N o t e

3
Programming
26
Version Info
Space Combine
N o t e :
A space cannot be combined with itself.
Version Info
Echo ACP App:
12.34.0.0.0.0.05
DRd: 2.1.0.0.0.0.4
FLO: 1.0.0.0.0.0.6
DALI: 1.0.0.0.0.0.7
Echo Protocol:
12.3.5.7.1.1.1
Echo PHY:
12.3.5.7.1.2.1
The “Version Info” menu displays the current full software
version numbers, including build numbers, for each software
type installed in the rack.
FLO and DALI options only appear if they are presently installed
in the host DRd rack. Each DRd may have only 1 option
installed, except when the rack type is the DRd12AX12X. In this
case, you will notice a “1” or “2” following the software version
type. This indicates to which rack the software relates.
Space Combine
Space 1:
2
Space 2:
1
Space 4:
4-6
Space 5:
4-6
Space 6:
4-6
The “Space Combine” menu displays each configured space for
this Echo ACP and lists other spaces, by their numbers, the
space is combined with for control.
Space 1 is created by default. When no other spaces have been
created, and therefore Space 1 is not combined with anything,
None displays.
