Echo ACP Configuration Manual
File Operations Menu
Save Rack Configurations
The “Save Rack Configs” operation saves two files to the selected media destination with
the same (user selected) filename but with different file extensions. The Echo architectural
configuration receives a “.eacp” file extension and the dimming rack configuration receives
a “.drd” file extension. Files are always saved to the root directory of the removable media
device.
Step 1:
Install the removable media into the correct slot on the front of the Echo ACP.
Step 2:
Scroll to select “Save Rack Configs” from the “File Operations” menu and press
enter (
). The “Save Rack Configs” menu list will display.
Step 3:
Press enter (
) to change the rack configuration filename. The “Save Filename”
menu list displays for selection. You may choose from a selection of
configuration filenames.
Step 4:
Press enter (
) to accept the filename selection. The display returns to the
“Save Rack Configs” menu list.
Step 5:
Beneath the configuration filename lists the installed and available removable
media. Scroll to select the desired or available media type and press enter (
).
If an error has stopped the saving process, simply follow the instructions on the
display. When the configuration files are saved successfully, the “File
Operations” menu displays.
N o t e :
When the removable media is either not
installed properly or is not an approved type,
you will receive a display notification.
Check the media to ensure it is the proper type.
Reference
. Then
press enter (
) to continue.
W A R N I N G :
Do not remove media during this process. Doing so could damage your
media or prevent your system from operating properly.
Save Rack Configs
Save Dimming Config
Load Dimming Config
Save Arch Config
Load Arch Config
Restore Defaults
Update Firmware
File Operations
The “File Operations” menu provides you with the tools to save
and load your Echo ACP and dimming configurations, restore
system default properties and update firmware.
Operations from this menu, with the exception of “Restore
Defaults”, provide operations for saving and loading of files
using SD media and USB flash drive removable media types.
Save Rack Configs
Name:
Unison1
Save to USB Media
Save to SD Media
Save Filename
Unison1
Unison2
Unison3
Unison4
Unison5
Unison6
Unison7
Save Rack Configs
Name:
Unison2
Save to USB Media
Save to SD Media
Cannot Perform Save
SD or USB
Removable Media
was not detected
or is invalid.
Please insert media
and retry.
