Programming
36
sACN Universe
This setting is automatically defaulted to sACN Universe “1”. sACN Universe corresponds
to the input universe of control that the Echo ACP will receive control input from. The valid
range is 1 - 63999.
Step 1:
Use the touch wheel to scroll to “sACN Universe” and press enter (
) to select.
Step 2:
Use the touch wheel to scroll or use the numeric button pad to specify sACN
universe. Press enter (
) to select.
Step 3:
Use the touch wheel to scroll to the next setup option or scroll to “Apply Changes
Only” or “Apply All”. Press enter (
) to select.
sACN Start Address
sACN Start Address corresponds to the first sACN address you wish to patch DRd dimmer.
The DRd always receives its sACN from the network connected sACN control device. This
setting is automatically defaulted to sACN Start Address “1”.
A universe of sACN is a group of 512 contiguous control channels. When using the “sACN
Start Address” menu feature, addresses may start at one or any number up to 512 minus
the number of dimmers in the enclosure, depending on the type of enclosure(s) you are
programming.
Step 1:
Use the touch wheel to scroll to “sACN Start Address” and press enter (
) to
select.
Step 2:
Use the touch wheel to scroll or use the numeric button pad to specify the start
address. Press enter (
) to select.
Step 3:
Use the touch wheel to scroll to the next setup option or scroll to “Apply Changes
Only” or “Apply All”. Press enter (
) to select.
Space
Editing this setting allows assignment of all dimmers in the enclosure to a single Space. By
default, Space 1 is selected. As a result of editing this setting, all dimmers will receive
default and unique circuit numbers for the specified Space. By default, these circuit
numbers are equal to the dimmer number and viewable in the
menu.
Step 1:
Use the touch wheel to scroll to “Space” and press enter (
) to select.
Step 2:
Use the touch wheel to scroll or use the numeric button pad to specify the Space
number. Press enter (
) to select.
Step 3:
Use the touch wheel to scroll to the next setup option or scroll to “Apply Changes
Only” or “Apply All”. Press enter (
) to select.
Temp
This setting is automatically defaulted for you. When the dimmer rack’s voltage is set or
defaulted to 100-130, 240, or 277V AC, “Fahrenheit” will be the default. When the dimmer
rack’s current voltage is set or defaulted to 230 V AC, “Celsius” is the default.
Step 1:
Use the touch wheel to scroll to “Temp” and press enter (
) repeatedly to cycle
through the options.
Step 2:
When the desired value is displayed, use the touch wheel to scroll to the next
setup option or scroll to “Apply Changes Only” or “Apply All”. Press enter (
) to
select.
N o t e :
If the selected start address doesn’t allow for unique addresses for each dimmer
in the enclosure (for example a DRd6 with a start address of 506), the dimmers
outside of the allowable range of 512 will remain un-patched.
