ETC Echo Architectural Control Processor (ACP) v1.0.0 User Manual
Page 53

3
Programming
48
Step 5:
Scroll to “Record” and press enter (
). The current state of the output levels are
recorded into the currently selected Step with the set Fade and Hold times.
Step 6:
Scroll to “Insert Step After” and press enter (
). A new Step will be added into
the Sequence directly after the currently selected Step. Up to 6 steps are allowed
per Sequence, therefore when 6 Steps are created. The “Insert Step After” menu
option will no longer be available for selection.
Step 7:
Scroll to “Delete Step” to delete the currently selected Step and shift all
subsequent steps, if any are created, by one to close the gap. The “Delete Step”
menu option will not be available for selection when there is only one Step in the
Sequence.
