Echo ACP Web Interface
76
Sequences
The “Sequences” page allows you to playback sequences that have been pre configured in
the Echo ACP. For more information on Sequences, see
.
All Spaces that have been pre configured into the Echo ACP will be available from the
“Select Space” drop down list at the top of the screen. The system defaults to Space 1. For
additional information on Spaces, see
Files
The “Files” page allows you to upgrade new versions of firmware to the Echo ACP, and
retrieve or upload the Arch Configuration or Dimming Configuration.
To upload a file:
Step 1:
Select the file type (Arch Configuration, Dimming Configuration, or Firmware) by
clicking the appropriate radio button.
Step 2:
Use the “Choose File” button to navigate to and select the desired file on your
connected device.
Step 3:
Click the “Send File” button to begin the upload process.
To retrieve a configuration:
Step 1:
Select the file type (Arch Configuration or Dimming Configuration) by clicking the
appropriate radio button.
Step 2:
Click “Retrieve Configuration” button. The system will compile the selected
configuration.Once compiled, the configuration file will be available for selection.
The result of this step is determined by the settings in your selected browser.
