Backlight
The backlight setting specifies the performance of the user interface backlight. When the
backlight setting is set to “Auto”, the inactivity timer is also the backlight timer. If the
inactivity timer is set to “Never”, the backlight will time out after one minute.
Backlight settings include:
•
“Auto” (LCD dims when the inactivity timer has expired)
•
“On (the backlight is always on)
•
“Off” (the backlight is always off).
Step 1:
Use the touch wheel to scroll to “Preferences” from within the “Arch Setup” menu
and press enter (
). The Preferences menu list displays.
Step 2:
Use the touch wheel to scroll to “Backlight” and press enter (
) repeatedly to
cycle through the options.
Step 3:
When the desired value is displayed, use the touch wheel to scroll to the next
setup option or press back ( ) to return to the “Arch Setup” menu.
Language
The multi-language user interface includes English, Spanish, German and French.
Step 1:
Use the touch wheel to scroll to “Preferences” from within the “Arch Setup” menu
and press enter (
). The Preferences menu list displays.
Step 2:
Use the touch wheel to scroll to “Language” and press enter (
) repeatedly to
cycle through the options.
Step 3:
When the desired value is displayed, use the touch wheel to scroll to the next
setup option, or press back ( ) to return to the “Arch Setup” menu.
Space Setup
Step 1:
Use the touch wheel to scroll to “Space Setup” from within the “Arch Setup” menu
and press enter (
). The Space Setup menu displays with Space 1 populated
by default.
Step 2:
Use the touch wheel to scroll, then press enter (
) to select a row for Space
selection. The focus changes to the Space column.
Step 3:
Use the touch wheel or use the numeric keypad to specify the space number.
You will not be allowed to specify a Space number that is currently already
specified. Press enter (
) to set the selection.
N o t e :
If a configured Space is changed to another number and has dimmers or circuits
assigned to it, a dialog displays for confirmation that you want the configured
circuits reassigned to this new Space. Select “Yes” to reassign configured circuits
to the new Space or select “No” to cancel and return to the previous setup.
Space Setup
Space Name
1
Space
1
5
Space
5
14
Space 14
16
Space 16
--
Unused
--
Unused
--
Unused
--
Unused
The Echo ACP supports configuration of up to 8 of the available
16 Spaces in an Echo system. Space 1 is available as default.
Space names are defaulted to match the space number. For
example, if 1 is the selected Space, the Space Name will be
“Space 1”.
