ETC Echo Architectural Control Processor (ACP) v1.0.0 - Manual (Page 27)

2
Echo ACP Basic Navigation 22
Status / Errors Messages Generated by the DRd Dimming Engine
Message Displayed Description Action
Rack Error / Rack
Overtemp
Ambient temperature is
above rated temperature
range. All dimmers in the enclosure are disabled
from use until the ambient temperature is
within an acceptable operating range.
Rack Warning / High
Operating Temp
Ambient temperature is
approaching maximum
temperature.
Correct the ambient temperature to within
specification.
Rack Warning / Low
Operating Temp
Ambient temperature is
below rated temperature
range.
Correct the ambient temperature to within
specification.
Rack Error/Freq out of
Range Input power frequency is
out of operating range.
All dimmers in the enclosure are disabled
from use until the input power frequency is
within acceptable operating range.
Dimmer Overtemp/
Dimmers ## and ## Dimmer is in an overtemp
condition.
The specified dimmer automatically
disables. Verify loads are within
acceptable limits. Try swapping dimmer
modules to isolate if the problem is within
a module.
Rack Error/Phase 1
Missing
Phase A is off. Check mains power feed.
Rack Error/Phase 2
Missing
Phase B is off. Check mains power feed.
Rack Error/Phase 3
Missing
Phase C is off. Check mains power feed.
Rack Error/Phase 1
Overvoltage Phase A voltage is above
rated voltage range.
All dimmers in the enclosure are disabled
from use until Phase A voltage is within
acceptable operating range.
Rack Error/Phase 2
Overvoltage Phase B voltage is above
rated voltage range.
All dimmers in the enclosure are disabled
from use until Phase B voltage is within
acceptable operating range.
Rack Error/Phase 3
Overvoltage Phase C voltage is above
rated voltage range.
All dimmers in the enclosure are disabled
from use until Phase C voltage is within
acceptable operating range
Rack Error/Phase 1
Undervoltage Phase A voltage is below
rated voltage range.
Correct input voltage to acceptable range.
Rack Error/Phase 2
Undervoltage Phase B voltage is below
rated voltage range.
Correct input voltage to acceptable range.
Rack Error/Phase 3
Undervoltage Phase C voltage is below
rated voltage range.
Correct input voltage to acceptable range.
Rack Error/Fan Error or
Failure Fan is not operating
properly.
Verify that the fan is not obstructed.
