Echo ACP Configuration Manual
Dimming Setup Menu
Dimming setup can be simplified by using the default values as found in the
menu. When viewing the “Dimming Setup” menu, press the control menu shortcut
(
) button to directly access set levels and dimmer check functions.
Dimmer Setup
The “Dimmer Setup” menu provides the ability to set each dimmer’s module type and
properties individually, one dimmer at a time, or set by a range of dimmers using the (and)
and (thru) buttons on the numeric keypad. The range of dimmers cannot exceed the
number of dimmers in the host enclosure.
Each object in the “Dimmer Setup” menu allows you to specify alternative dimmer
properties about each dimmer channel including the dimmer module type, the mode of
operation, curve, etc. Refer to
Dimmer Module Defaults, page 65
for a listing of standard
dimmer properties.
Step 1:
Scroll to select a dimmer or use the numeric keypad to specify a range of
dimmers. Press enter (
) to edit the selected dimmer properties.
Step 2:
Scroll to “Module Type” property and press enter (
). The “Module Type” menu
will display all possible dimmer module types available for the host rack and
voltage.
Step 3:
Scroll to select the desired module type from the available list and press enter
(
). The display returns to Dimmer Setup.
N o t e :
Refer to your architectural panel schedule when patching dimmers to DMX and
sACN inputs.
N o t e :
When specifying a range of dimmers, properties that are not equal among the
selected dimmers will display as empty property fields. Any edits made to the
empty property fields are applied to the entire selected range of dimmers.
Specifying a different module type defaults all dimmer properties for the selected
range.
Dimming Setup
Dimmer Setup
Patch DMX Input
Patch sACN Input
Emergency Setup
Quick Rack Setup
Push to Set Levels
The “Dimming Setup” menu provides a range of options to
setup a host DRd enclosure. Use the “Dimming Setup” menu to
specify dimmer module types, customize dimmer properties,
patch the rack dimmers to the specified DMX input and sACN
input addresses, and setup emergency operation for the
dimmers in the rack configuration.
Dimmer Setup
Module Type:
D20
Mode:
Normal
Curve:
Mod Square
Threshold:
1
%
Voltage Reg:
On
Max
Scale:
118
V
Min Scale:
6
V
Dyn Preheat:
Off
Transformer mode:
On
DMX Res:
Hi 16 bit
Space:
1
Zone:
1
Circuit:
1
Name:
Circuit
1
1
In the “Dimmer Setup” menu, each dimmer in the rack defaults
to a standard dimmer module (D20, AD20, ED15) depending on
the rack voltage selection and each dimmer module defaults
with standard properties.
