Echo ACP Configuration Manual
Status / Error Messages
Status messages display on both the dimming rack status display and the Arch Control
Status display. When the Echo ACP is installed in a DRd enclosure, use the touch wheel
to scroll clockwise (
) to view the Arch Control Status display.
Status messages provide you with system wide, rack specific or even just dimmer specific
information including errors. Important errors may suppress display of other existing errors
on the status display. For a complete list of errors see
Status / Error Messages Generated
and
Status / Errors Messages Generated by the DRd Dimming Engine
.
Status / Error Messages Generated by the Echo ACP
Message Displayed
Description
Action
System OK
No errors exist
No action required for normal operation.
Emergency Active
Panic/Emergency bypass
operation is active
The programmed Emergency bypass
(Panic) look is played. If load shedding is
set to “On” all loads not in emergency are
shed. Also the dimming setup, restore
defaults, load dimming configuration, and
update firmware menus will be locked out
from user intervention.
Dimming Firmware /
Mismatch Detected
Firmware version
mismatch between the
DRd enclosure and the
Echo ACP.
This is resolved through a firmware
update procedure.
Dimming Engine
Communication Failure!
The Echo ACP cannot
communicate with the DRd
dimming engine properly.
The error is clearable by correcting the
failure point. Contact ETC Technical
Services for troubleshooting assistance
as needed.
ACP and DRd
Configuration Mismatch
Occurs when the dimming
configuration stored locally
on the Echo ACP does not
match the configuration
running within the DRd
dimming engine.
The menu locks out additional navigation
and requires you to confirm use of either
the dimming rack configuration or use of
the dimming configuration as stored on
the Echo ACP. Alternatively you can
select “Quick Rack Setup” to create a new
configuration.
AX12X ACP Position
Error
An error display warns you
when the Echo ACP is
installed in “Rack 2” of a
cross-bussed application.
Occurs only when the Echo ACP is
installed in a cross-bussed host DRd
enclosure. This error cannot be cleared
except by correctly installing the AX12X
interconnect cable or by moving the Echo
ACP to the enclosure with the
interconnect cable end labeled “Rack 1”.
DMX Input Data Error
DMX serial error occurred. Verify proper DMX data line termination.
Ethernet/Connection
Lost
Ethernet disconnect,
connectivity was active
then lost.
Troubleshoot Ethernet infrastructure for a
device or cable failure.
