3
Programming
42
When “Automatic is selected:
Scroll to “Apply and Exit”, then press enter (
). The display returns to the Network
Settings menu.
When “Manual” is selected:
Press enter (
) to manually select each of the IP Address settings. By default, the manual
IP settings for the Echo ACP are: IP Address 10.101.166.101, Subnet Mask 255.255.0.0,
and Gateway 10.101.1.1.
a: Scroll to “IP Address” and press enter (
). The selection changes to the
first octet of the IP Address. Use the numeric keypad to specify the first
numeric octet, then press enter (
). Repeat for each octet of the IP
Address.
b: Scroll to “Mask” and press enter (
). The selection changes to the first
octet of the Subnet Mask. Use the numeric keypad to specify the first
numeric octet, then press enter (
). Repeat for each octet of the Subnet
Mask.
c: Scroll to “Gway” and press enter (
). The selection changes to the first
octet of the Gateway. Use the numeric keypad to specify the first numeric
octet, then press enter (
). Repeat for each octet of the Gateway Address.
d: Scroll to “Apply and Exit”, then press enter (
). The display returns to the
Network Settings menu.
sACN Universes
Step 1:
Use the touch wheel to scroll to “sACN Universes” and press enter (
). The
sACN Universes menu displays.
Step 2:
Scroll to select the Universe for editing and press enter (
).
Step 3:
Use the numeric keypad or scroll wheel to specify the sACN universe number
between 1 and 63999, then press enter (
) to set.
Step 4:
Repeat for each Universe available as control input into the Echo ACP, up to four
universes total.
Step 5:
Press the back ( ) button to set the values and return to the Network Settings
menu.
N o t e :
When “Automatic” is the selected IP Addressing mode, the IP Address, Gateway
and Subnet Mask fields do not display. To identify the current IP Address,
N o t e :
An sACN universe entered as “0” will display as “-” in the sACN Universes display
to indicate the universe is unused.
sACN Universes
Universe A:
1
Universe B:
-
Universe C:
-
Universe D:
-
Configure up to four streaming ACN (sACN) universes for input
patching to the circuits in the enclosure. sACN universe 1 is
associated by default.
