Programming
52
Save Arch Configuration
The “Save Arch Config” process saves only the architectural configuration to the root
directory of the removable media device.
Step 1:
Install a removable media device (either SD media card or USB flash drive) into
the correct slot on the front of the ACP.
Step 2:
Scroll to “Save Arch Config” from within the “File Operations” menu and press
enter (
). The “Save Arch Config” menu list displays. The filename defaults to
the name of the currently running configuration.
Step 3:
To change the architectural configuration filename press enter (
). The “Save
Filename” menu list displays for selection. You may choose from a selection of
configuration filenames.
Step 4:
Press enter (
) to accept the filename selection. The display returns to the
“Save Arch Config” menu.
Step 5:
Beneath the configuration filename lists the available removable media. Scroll to
select the desired or available media type and press enter (
) to save the
architectural configuration. The configuration file saves to the root directory of the
selected removable media device. If an error has stopped the saving process,
simply follow the instructions on the display. When the configuration files are
saved successfully, the “File Operations” menu displays.
W A R N I N G :
Do not remove media during this process. Doing so could damage your
media or prevent your system from operating properly.
N o t e :
When the removable media is either not
installed properly or is not an approved type,
you will receive a display notification.
Check the media to ensure it is the proper type.
Reference
. Then
press enter (
) to continue.
Save Rack Configs
Save Dimming Config
Load Dimming Config
Save Arch Config
Load Arch Config
Restore Defaults
Update Firmware
File Operations
Unison1
Unison2
Unison3
Unison4
Unison5
Unison6
Unison7
Save Filename
Save Arch Config
Name:
Unison1
Save to USB Media
Save to SD Media
Cannot Perform Save
SD or USB
Removable Media
was not detected
or is invalid.
Please insert media
and retry.
