45
Echo ACP Configuration Manual
Arch Control Menu
Presets
Preset activation, deactivation, and record use the specified Space as the control scope.
Each Space can have one single active preset at a time. Activation plays latest takes
precedence (LTP), on a per Space basis. Each Space may have a different active preset,
or it may have no preset active as the Preset may be “Off”.
Preset defaults (including levels for controllable outputs (dimmers):
•
Preset 1 - 100% (full), Preset 2 - 75%, Preset 3 - 50%, Preset 4 - 25%, repeating until
the last supported Preset.
•
Fade Time - 2 seconds is the default fade time. Each preset supports a unique fade
time.
Scroll to select “Presets” from the “Arch Control” menu and press enter (
). The first
editable option in this menu list is Space. This menu selection allows configuration of the
pre-configured Spaces only. Reference
Edit the Space number
Step 1:
Press enter (
), the selection changes to the Space number.
Step 2:
Using the scroll wheel, scroll through the available pre-configured Spaces for the
Echo ACP. Use of the numeric keypad is allowed, but specification of a Space
that is not already pre-configured will not be allowed. Press enter (
) to accept
the selection.
Preset Status
A currently active Preset will display (read-only) on the line directly below. If no Preset is
active for the selected Space, “No Active Preset” will display instead.
Edit the Preset number
Step 1:
Scroll to “Preset #” and press enter (
), the selection changes to the Preset
number.
Step 2:
Using the scroll wheel or numeric keypad, specify the Preset number for edit and
press enter (
). Each Space contains Presets numbered between 1 and 64.
Change Preset State (read only)
When the currently selected Preset is NOT active, “Activate” displays for selection on the
following line.
When the currently selected Preset is active, “Deactivate” displays for selection on the
following line.
Arch Control
Presets
Sequences
The “Arch Control” menu provides access to architectural
control objects such as presets and sequences.
Presets
Space
1
Preset 15 Active
Preset #:
12
Activate
Record
Fade Time: 0 min
The “Presets” menu provides the tools to edit the assigned
Space, display preset status, activate, deactivate, record, and
configure fade timing for the 64 built-in presets.
The lowest configured Space displays by default. See
for information to configure Spaces.
