Echo ACP Configuration Manual
About Menu
About Dimmer
By default, the “About Dimmer” menu automatically selects and displays the data for the
first dimmer in the rack. Notice the title bar displays the selected dimmer number.
Use the touch wheel to scroll to a different dimmer or use the numeric button pad to specify
the dimmer number. Dimmer parameter data updates when a new dimmer is selected.
Press enter (
) to view additional source details about your selected dimmer. The display
switches between dimmer property and dimmer source data information. To exit the “About
Dimmer menu and return to the previous menu press the back button ( ).
Levels Summary
Valid input control sources include:
•
DMX input - displayed as DMX
•
streaming ACN - displayed as sACN
•
Set levels - displayed as Set
•
Preset or Zone levels - displayed as Arch
•
Panic/Emergency - displayed as Emerg
•
No active control input - displays as ---
Use the touch wheel to scroll through all channels in the list or use the numeric button pad
to specify a channel. To exit the About DMX Level Data menu and return to the previous
menu press the back button ( ).
N o t e :
The “About” menu is provided for you to view information only. There are no
editing tools or menu lists available.
N o t e :
“Current Level” is the actively controlled level from the controlling data source for
this dimmer.
1 About Dimmer
2 Levels Summary
3 Version Info
4 Space Combine
About
The “About” menu provides you direct access to view
details about your dimmers, current level summary
data, software version information, and information
about which spaces in your Echo ACP configuration
have combined control.
About Dimmer
1
DMX address:
125
sACN address:
1234/123
Module Type:
D20F
Mode:
Fluorescent
Space:
Space
1
Current Level:
70%
< p u s h E n t e r f o r m o r e >
About Dimmer
1
Current Level:
70%
DMX Level: 45%
sACN Level:
0%
Arch Level:
33%
Set Level: 0%
Panic/Emer: 100%
< p u s h E n t e r f o r m o r e >
Dim Ckt Src Level
1 1 DMX
255
2 24
sACN
128
3 3 Arch
75
4 4 ---
---
5 5 DMX
255
6 6 Emerg
255
7 7 Set
0
The “Levels Summary” menu shows each dimmer position in the
enclosure as well as the associated circuit number, the winning
control source, and its actively controlled level (current level)
from the controlling data source for the dimmer.
Levels are displayed in values 0 - 255.
