39 Echo ACP Configuration Manual
Power On Behavior
Power On Behavior may be set to “None”, or configured to execute an action, such as
playing a specific preset or a sequence.
Step 1: Use the touch wheel to scroll to “Data Loss & Power On” from within the “Arch
Setup” menu and press enter (
). The DMX Loss Behavior, ACN Loss
Behavior, and Power On Behavior menu lists display. Notice the three settings
are separated vertically on the screen. You cannot select the heading, only the
“Mode” and options from within.
Step 2: Use the touch wheel to scroll to Power On Behavior “Mode” and press enter
(
). Follow the on screen choices to make an action selection.
Preferences
Click Volume
Set the “Click Volume” which plays an audible sound when using the touch wheel to scroll
or the buttons to select.
Step 1: Use the touch wheel to scroll to “Preferences” from within the “Arch Setup” menu
and press enter (
). The Preferences menu list displays.
Step 2: Use the touch wheel to scroll to “Click Wheel” and press enter ( ) repeatedly
to cycle through the options “Low”, “High”, or “Off”.
Step 3: When the desired value is displayed, use the touch wheel to scroll to the next
setup option or press back ( ) to return to the “Arch Setup” menu.
Inactivity Time
Inactivity time is the specified amount of time after which the user interface times out to the
status display. The inactivity time is also the backlight timer (when backlight is set to Auto)
and the number navigation timer for any unfinished number navigations. Time setting
options include “Never”, “30secs”, “1min”, “5min”, and “15min”. Default is set to “1min”. If
the inactivity timer is set to “Never”, the backlight will time out after one minute.
A wake event (any button press) wakes the main menu and backlighting. Any touch wheel
use wakes the status display and backlighting.
Step 1: Use the touch wheel to scroll to “Preferences” from within the “Arch Setup” menu
and press enter (
). The Preferences menu list displays.
Step 2: Use the touch wheel to scroll to “Inactivity Time” and press enter ( ) repeatedly
to cycle through the options.
Step 3: When the desired value is displayed, use the touch wheel to scroll to the next
setup option or press back ( ) to return to the “Arch Setup” menu.
N o t e : Selecting “Play Preset” or “Play Sequence” as the behavior mode requires
additional parameter specifications. Only presets and sequence actions that are
assigned to spaces that are pre-configured for this Echo ACP are allowed.
Click Volume: Low
InactivityTime: 1 min
Backlight: Auto
Language:
English
Preferences
“Preferences” is a menu list of available settings related to the
Echo ACP user interface such as the touch wheel’s click
volume, inactivity time setting, the backlight time setting before
the backlight dims, and the language setting for the menu.
Preferences stay with the ACP not the configuration file and
therefore only need to be set once.
