toggle between positive and negative. This is to specify the slope of
the start arm signal. Press the softkey under STOP to toggle between
positive, negative and time. This is to specify how measurement
should stop. Positive and negative specifies the slope of the stop arm
signal. Time is to set the duration of measurement. As time is
selected, use the numeric keypad or the arrow keys to input a desired
duration value (refer to Ch.4.2.1). The time unit will be shown on the
top-right corner.
Remote Interface Command
Auto arming:
[:SENSe]:TOTalize:ARM[:STARt]:SOURce IMMediate
[:SENSe]:TOTalize:ARM:STOP:SOURce IMMediate
Time arming:
[:SENSe]:TOTalize:ARM[:STARt]:SOURce IMMediate
[:SENSe]:TOTalize:ARM:STOP:SOURce TIMer
[:SENSe]:TOTalize:ARM:STOP:TIMer
External arming:
[:SENSe]:TOTalize:ARM[:STARt]:SOURce EXTernal
[:SENSe]:TOTalize:ARM[:STARt]:SLOPe POSitive|NEGative
[:SENSe]:TOTalize:ARM:STOP:SOURce EXTernal
[:SENSe]:TOTalize:ARM:STOP:SLOPe POSitive|NEGative
[:SENSe]:TOTalize:ARM:STOP:SOURce TIMer
[:SENSe]:TOTalize:ARM:STOP:TIMer
For time interval measurement:
Press the softkey under GATE to toggle between auto and external. Press
the softkey under DONE to finish the selection.
■ If Auto Arming is selected, the counter automatically starts
continuous measurements. Besides, users can press the softkey
under Delay* to toggle between None, Time and Event. In the
settings of Time and Event, users also can input parameters
STARt:SOURce STOP:SOURce
IMMediate
IMMediate
Auto
----
IMMediate
TIMer
Time
----
EXTernal
EXTernal
EXTERNAL
POS,NEG
EXTernal
TIMer
EXTERNAL
Time
Front-Panel Gating Settings
GATE STOP
