134 134 134 134
Voltage range -5.125V to 5.125V for ×1 attenuation
-51.25V to 51,25V for ×10 attenuation
Voltage resolution
0.0025V for ×1 attenuation
0.025V for ×10 attenuation
default (@1)
range (@1)
:MEASure[:SCALar][:VOLTage]:PERiod? [ [,]]
[,(@1)|(@2)|(@3)]
Sets the measurement arming to “digits” and measures the period.
The and parameters are used to configure the number of digits
of resolution arming setting.
The Channel 1 and Channel 2 share the same trigger setting so that the measurement channel
has auto-trigger enabled at 50% with a positive slope.
Ch1, Ch2
Default 100 ns
Range
2 ns ~ 10 sec
Resolution should be within 10% of the input
period for optimum arming configuration
Ch3
Default 2 ns
Range 0.17 ns ~ 2.67 ns
Resolution should be within 10% of the input
period for optimum arming configuration
Ch1, Ch2
Default Value which indicates 4 digits of resolution for the
specified
Range
1E-23 ~ 1E-2 sec (15 to 3 digits of resolution)
Resolution should use a mantissa of 1.0 and be an
even power of 10
Ch3
Default Value which indicates 4 digits of resolution for the
specified
Range
1E-24 ~ 1E-11 sec (15 to 3 digits of resolution)
Resolution should use a mantissa of 1.0 and be an
even power of 10
Default (@1)
Range (@1)(@2)(@3)
:MEASure[:SCALar][:VOLTage]:PHASe? [(@1),(@2)]
Sets the measurement arming to “auto” and measures Phase.
