The Channel 1 and Channel 2 share the same trigger setting so that the measurement channel
has auto-trigger enabled at 50% with a positive slope.
Default (@1),(@2)
Range (@1),(@2)
:MEASure[:SCALar][:VOLTage]:PTPeak? [(@1)|(@2)]
Makes Peak-to-Peak measurement.
Default (@1)
Range (@1)|(@2)
:MEASure[:SCALar][:VOLTage]:CENTer? [(@1)|(@2)]
Measures center voltage.
Default (@1)
Range (@1)|(@2)
:MEASure[:SCALar][:VOLTage]:TINTerval? [(@1),(@2)]
Measures Time Interval.
The first channel is the start channel and the second channel is the stop channel.
The Channel 1 and Channel 2 share the same trigger setting so that the measurement channel
has auto-trigger enabled at 50% with a positive slope.
The measurement arming is set to “auto” with no delay. The input routing is coupled to separate
inputs.
Default (@1),(@2)
Range (@1),(@2)
:MEASure[:SCALar][:VOLTage]:TOTalize:TIMed? [][,(@1)]
Makes Totalize measurement during the specified .
The trigger settings are coupled so that the measurement channel has auto-trigger
disabled with a positive slope.
Default 0.1 sec
Range
1E-3 to 1,000 sec
Resolution
1E-5 sec
Default (@1)
Range (@1)
:MEMory:NSTates?
Queries the number of available *SAV/*RCL states in the counter.
