} Settings
}
Axis type
Axis param
Homing param
Position set
Password
4. Control panel (MTR-DCI-...-H2IO)
4-11
Festo P.BE-MTR-DCI-IO-EN en 1209d
4.2.3 Menu [Settings]
Warning
Damage to or impairment of the mechanical components
With all teach procedures the motor turns or the connected
axis starts to move.
• Make sure that:
– nobody can place his/her hand in the positioning
range
– there are no objects in the positioning range.
Parametrizing the axis system and programming the position
sets:
1. Select [Settings] in the main menu with the arrow buttons
and press the button.
2. Select:
– the axis type [Axis type]
– the axis parameters [Axis param]
– the reference run parameters [Homing param]
– the position set table [Position set]
– the password setting [Password].
[Axis type] Design of the axis driven by the MTR-DCI (parameters see
chapter 5.2.1)
[Axis type] Description
[Type DMES-...] Festo positioning axis
[Rotation drive] Specific rotation axis
[User config] Specific linear axis
[Save...] Save parameter in EEPROM
