4. Control panel (MTR-DCI-...-H2IO)
4-9
Festo P.BE-MTR-DCI-IO-EN en 1209d
[Pos. set table] Menu command for displaying the following entries in the
position set table:
[Pos. set table] Description
Nr Number of the position set (0...14)
a/r absolute (a) or relative (r) positioning
Pos Target position
Vel Positioning speed
[Axis param] Menu command for displaying the following axis parameters
and data:
[Axis param]
1)
Description
v max Maximum positioning speed
x min Stroke limitation: Software end position,
negative
x max Stroke limitation: Software end position,
positive
x 0 Offset axis zero point
feed 2) Feed constant
1) Measuring unit depends on measuring system set
2) Not for axis type “Rotation drive”
