7.2.12 Motor Thermostat Set Up

This sub-menu allows you to configure the DLCM to interact with the pump motor thermostat.
Depending on the application, it is possible for the fan cooled pump motor to run at low RPM and high
torque, which degrades the effectiveness of the fan and can cause heat build up.

For equipment safety, the DLCM can be programmed to have one of the following responses if the
Motor Thermostat activates:

−

Shut the motor off, (no alarm) (no restart)

−

Trigger the alarm relay, (motor stays on)

−

Shut the motor off and trigger the alarm relay, (no restart)

−

Shut the motor off, trigger the alarm relay, and then restart the motor when the Motor Thermostat
resets,

−

Shut the motor off and then restart the motor when the Motor Thermostat resets (No alarm),

−

Ignore the thermostat input. (not recommended)

Motor Thermostat Set Up Procedure

1. Press [MENU] once and then press [UP] or [DOWN] until the display reads {–MENU– / MOTOR

THERMOSTAT}.

–MENU–

MOTOR THERMOSTAT

2. Press [ENTER] and the {MOTOR THERMOSTAT / NORMALLY CLOSED} screen is displayed.

MOTOR THERMOSTAT

NORMALLY CLOSED

Press [ENTER] to accept the {NORMALLY CLOSED} configuration. Go to step 4.
or
Press [UP] and the {MOTOR THERMOSTAT / INACTIVE} screen is displayed.

MOTOR THERMOSTAT

INACTIVE

If the {MOTOR THERMOSTAT} is to be configured as {INACTIVE}, press [ENTER] and you are
returned to the {–MENU– / MOTOR THERMOSTAT} screen.

F YOU SET

{MOTOR THERMOSTAT}

{INACTIVE}

IT IS POSSIBLE FOR THE MOTOR

WINDINGS TO OVERHEAT LEADING TO PREMATURE MOTOR FAILURE AND POSSIBLE HAZARDOUS
CONDITIONS

(

FIRE

3. Pressing [UP] from the {MOTOR THERMOSTAT / INACTIVE} screen will display the {MOTOR

THERMOSTAT / NORMALLY OPEN} screen.

MOTOR THERMOSTAT

NORMALLY OPEN

Press [ENTER] to accept the {NORMALLY OPEN} configuration.

4. The {MOTOR THERMOSTAT / MOTOR OFF? YES} screen is displayed.

MOTOR THERMOSTAT

MOTOR OFF? YES

Press [UP] to select between {YES} or {NO}.
If you want the motor to turn off when the thermostat activates, (recommended), set {MOTOR OFF?}
to {YES}.
Press [ENTER] to accept the desired configuration.

F YOU SET

{MOTOR OFF?}

{NO}

IT IS POSSIBLE FOR THE MOTOR WINDINGS TO OVERHEAT

LEADING TO PREMATURE MOTOR FAILURE AND POSSIBLE HAZARDOUS CONDITIONS

(

FIRE
