Configuring the Switch
3-8
3
GVRP Status Enables GVRP on the switch 3-158
802.1Q Tunnel
Configuration
Enables 802.1Q (QinQ) Tunneling 3-170
Basic Information Displays information on the VLAN type supported by this switch 3-159
Current Table Shows the current port members of each VLAN and whether or
not the port is tagged or untagged
3-159
Static List Used to create or remove VLAN groups 3-161
Static Table Modifies the settings for an existing VLAN 3-162
Static Membership by Port Configures membership type for interfaces, including tagged,
untagged or forbidden
3-164
Port Configuration Specifies default PVID and VLAN attributes 3-165
Trunk Configuration Specifies default trunk VID and VLAN attributes 3-165
Tunnel Port Configuration Adds an interface to a QinQ Tunnel 3-172
Tunnel Trunk Configuration Adds an interface to a QinQ Tunnel 3-172
Private VLAN 3-173
Information Displays Private VLAN feature information 3-174
Configuration This page is used to create/remove primary or community
VLANs
3-175
Association Each community VLAN must be associated with a primary VLAN 3-176
Port Information Shows VLAN port type, and associated primary or secondary
VLANs
3-177
Port Configuration Sets the private VLAN interface type, and associates the
interfaces with a private VLAN
3-178
Trunk Information Shows VLAN port type, and associated primary or secondary
VLANs
3-177
Trunk Configuration Sets the private VLAN interface type, and associates the
interfaces with a private VLAN
3-178
Protocol VLAN 3-179
Configuration Configures protocol VLANs 3-179
System Configuration Configures protocol VLAN system parameters 3-180
LLDP 3-181
Configuration Configures global LLDP timing parameters 3-181
Port Configuration Configures parameters for individual ports 3-183
Trunk Configuration Configures parameters for trunks 3-183
Local Information Displays LLDP information about the local device 3-186
Table 3-2 Main Menu (Continued)
Menu Description Page
