Configuring the Switch
3-218
3
• Port or Trunk – Specifies the interface attached to a multicast router.
Web – Click IGMP Snooping, Static Multicast Router Port Configuration. Specify the
interfaces attached to a multicast router, indicate the VLAN which will forward all the
corresponding multicast traffic, and then click Add. After you have finished adding
interfaces to the list, click Apply.
Figure 3-133 Static Multicast Router Port Configuration
CLI – This example configures port 1 as a multicast router port within VLAN 1.
Displaying Port Members of Multicast Services
You can display the port members associated with a specified VLAN and multicast
service.
Command Attributes
• VLAN ID – Selects the VLAN for which to display port members. (Range: 1-4093)
• Multicast IP Address – The IP address for a specific multicast service.
• Multicast Group Port List – Shows the interfaces that have already been
assigned to the selected VLAN to propagate a specific multicast service.
Console(config)#ip igmp snooping vlan 1 mrouter ethernet 1/14-296
Console(config)#exit
Console#show ip igmp snooping mrouter vlan 14-296
VLAN M'cast Router Port Type
---- ------------------ -------
1 Eth 1/1 Static
Console#
