Configuring the Switch
3-222
3
CLI – This example enables IGMP filtering and creates a profile number. It then
displays the current status and the existing profile numbers.
Configuring IGMP Filter Profiles
When you have created an IGMP profile number, you can then configure the
multicast groups to filter and set the access mode.
Command Usage
• Each profile has only one access mode; either permit or deny.
• When the access mode is set to permit, IGMP join reports are processed when a
multicust group falls within the controlled range. When the access mode is set to
deny, IGMP join reports are only processed when the multicast group is not in the
controlled range.
Command Attributes
• Profile ID – Selects an existing profile number to configure. After selecting an ID
number, click the Query button to display the current configuration.
• Access Mode – Sets the access mode of the profile; either permit or deny.
(Default: Deny)
• New Multicast Address Range List – Specifies multicast groups to include in the
profile. Specify a multicast group range by entering the same IP address for the
start and end of the range. Click the Add button to add a range to the current list.
• Current Multicast Address Range List – Lists multicast groups currently
included in the profile. Select an entry and click the Remove button to delete it from
the list.
Console(config)#ip igmp filter 4-298
Console(config)#ip igmp profile 19 4-298
Console(config)#end
Console#show ip igmp profile
4-302
IGMP Profile 19
IGMP Profile 25
Console#
