Command Line Interface
4-264
4
This shows that traffic matching the specifications for protocol group 2 will be
mapped to VLAN 2:
Priority Commands
The commands described in this section allow you to specify which data packets
have greater precedence when traffic is buffered in the switch due to congestion.
This switch supports CoS with four priority queues for each port. Data packets in a
port’s high-priority queue will be transmitted before those in the lower-priority
queues. You can set the default priority for each interface, the relative weight of each
queue, and the mapping of frame priority tags to the switch’s priority queues.
Priority Commands (Layer 2)
Console#show protocol-vlan protocol-group-vid
ProtocolGroup ID VLAN ID
------------------ -----------
2 VLAN2
Console#
Table 4-67 Priority Commands
Command Groups Function Page
Priority (Layer 2) Configures default priority for untagged frames, sets queue weights,
and maps class of service tags to hardware queues
4-264
Priority (Layer 3 and 4) Maps IP DSCP tags to class of service values 4-269
Table 4-68 Priority Commands (Layer 2)
Command Function Mode Page
queue mode Sets the queue mode to strict priority or Weighted
Round-Robin (WRR)
GC 4-265
switchport priority default Sets a port priority for incoming untagged frames IC 4-265
queue bandwidth Assigns round-robin weights to the priority queues GC 4-266
queue cos map Assigns class-of-service values to the priority queues IC 4-267
show queue mode Shows the current queue mode PE 4-268
show queue bandwidth Shows round-robin weights assigned to the priority queues PE 4-268
show queue cos-map Shows the class-of-service map PE 4-269
show interfaces switchport Displays the administrative and operational status of an
interface
PE 4-175
