Installation GPS 2000/2100
Ag Leader Technology
April 1998 7-4
excessively.
Note: Two mounting options are available:
•
Use the dual lock on the back of the unit to mount the GPS
2000/2100 on the combine glass.
•
Use the provided U-bracket.
3 Attach the 10-foot coaxial cable to the connector on the unit.
Note: Make sure you place the cable so that it is safe from damage.
4 Connect the GPS 2000/2100 to the Yield Monitor 2000/2100 with
the adapter cable, using the end with the single, nine-pin connector.
Step Action
5 Plug the other end of the cable, which has two, nine-pin connectors,
into the GPS 2000/2100.
Note: Match the labels on the two connectors with the labels on the
GPS 2000/2100 housing when you plug the cables into the unit.
6 The system is ready to run.
Installation
Questions If you have any questions or need further clarification, please call Ag
Leader Technology at (515) 232-5363.
* * *
