GPS 2000/2100 Operation
Ag Leader Technology
Apri1998 3-21
Follow these steps to change the NMEA message output rate:
Step Action
1 Set the unit in standard mode.
2 Press the SETUP key until NMEA MSG is above F1. Press F1.
3 Press the up arrow key to increment up the rate to a maximum of 20
seconds. To reduce the number from a setting higher than 1
second, press the down arrow key.
SAT OPT
This option is only functional on the GPS 2100 system. This option, found
under the setup key, allows the user to select which type of differential
correction will be used, either radiobeacon or satellite.
If the user chooses to use satellite differential then follow these steps to
activate this mode:
Step Action
1 Set the unit in standard mode.
2 Press the SETUP key until SAT OPT is above the F2 key. Press
the F2 key.
3 Press the F1 key to change DIFF SOURCE: from beacon to
satellite.
Step Action
4 The user must now decide which satellite differential service they
wish to use. The two options are RACAL or OMNISTAR.
Registration and purchasing information from both companies is
provided in this manual.
If the user chooses… Then…
RACAL Press the F2 key to select the
SAT SOURCE: that covers the
usage area best. Call the
RACAL subscription number
provided and give them the
number that is displayed to the
right of GPS SERIAL#:.
