GPS 2000/2100 Operation
Ag Leader Technology
Apri1998 3-13
Making Spot Marks
Follow these steps to make spot marks:
Step Action
1 Press the MARK key to access mark mode.
2 Select the desired field number/name.
3 Use the left or right arrow key to position the cursor on the mark
name in the lower left corner of the screen.
4 Use the up or down arrow keys to scroll through the 32 possible
mark names.
5 •
To make a mark with the desired name press the F key below the
corresponding mark name. Logging will begin for one logging
interval.
or
•
Follow the previous four steps, but with logging already active.
6 Another method of marking locations would be to select a mark
from standard mode:
a)
When the standard mode display appears with the default
information displayed the mark names are displayed above the F
keys.
b) Scroll through the 32 marks by pressing the up and down arrow
keys.
c) Press the F key below the desired mark name to make a mark.
The screen then switches to the mark screen and marks for one
interval.
d) To return to standard mode press RUN.
Note: Spot marks 1-4 will show on current software as attributes
such as a square, circle, triangle, or a X. Spot marks 5-32 will
show as a point or a dot.
NAV Key The following is a photo of the NAV screen. An explanation of the display
and the information it provides follows.
