118
Firmware Version 5.4
M
ANAGE
P
ATTERNS
S
PATIAL
S
ORT
Press: Map button > Guidance tab (in Mapping Toolbox) > New Pattern button
Spatial Sort allows the user to select any guidance
pattern in the display, sorted by distance from the
GPS location.
Pattern at the top of the list will be the closest to
current GPS location.
Check the box to show all
patterns.
I
MPORT
P
ATTERN
Press: Map button > Guidance tab (in Mapping Toolbox) > Manage Patterns button > Import button
>Select Pattern > Checkmark button
Display informs you when file has been successfully copied.
E
XPORT
P
ATTERN
Press: Map button > Guidance tab (in Mapping Toolbox) > Manage Patterns button > Select Pattern >
Export button
Display informs you when file has been successfully copied.
E
DIT
P
ATTERN
If you wish to rename a pattern, first press the Manage Patterns button on the Guidance Tab of the
Mapping Toolbox. Press
to enter a name for the pattern. The new pattern name now appears in
the pattern list of the Manage Patterns screen.
New
Pattern
Load Pattern
2014-01-02_
2014-01-02_
2014-01-02_
E headland
E headland 12
Slant east end
Slant east end
S side
2014-01-02_
40.0000
40.0000
40.0000
40.0000
40.0000
40.0000
40.0000
40.0000
40.0000
01/02/2014
03/14/2012
01/02/2014
01/02/2014
01/02/2014
03/14/2012
03/14/2012
03/14/2012
03/14/2012
Straight
Straight
Straight
Curve
Curve
Straight
Straight
Straight
Straight
Show all patterns
Show all patterns
Manage
Patterns
Import
Select Pattern
Manage
Patterns
Select Pattern
Export
