C H A P T E R 4 Administration Screen
93
System Role
The choice of System Role (or simply "role") depends in part on your
network’s topology and on the number of SA8220s installed. A single
SA8220’s role must be "Standalone." If two SA8220s are employed,
and you intend to use serial cable failover you must designate both
SA8220s as "standalone." If two SA8220s are employed, and you
intend to use Router Failover, one must be designated as the
"Primary" and the other as the "Backup." In such cases, the primary
SA8220 accepts all client requests and routes them according to its
configuration while the backup SA8220 monitors the primary and
comes online if the primary fails.
The system roles are defined below.
To select the SA8220’s System Role:
1. In the System Role box, click the appropriate button.
Active Routing Protocol
The SA8220 needs to know what your network’s active routing
protocol is (either OSPF or RIP).
1. In the Active Routing Protocol box, click the appropriate radio
button.
RIP Protocol
If your network’s active routing protocol is RIP, click the appropriate
button in the RIP Protocol box to specify the applicable RIP version.
Failover Method System Role
for
SA8220
#1
System Role
for
SA8220
#2
N/A (Single SA8220
Installation)
Standalone N/A
Router Failover Primary Backup
Serial Cable Failover Standalone Standalone
Disabled Standalone Standalone
