Displaying Versions system information
When you press , the active display is Versions. From the Versions display you can determine the:
• VCS revision level
• OCP firmware revision level
• PIC (Programmable Integrated Circuit) firmware revision level for:
• Address Bus PIC
• Battery PIC
• Power PC Processor
• Quasar
NOTE:
The terms PIC, PowerPC Processor, Quasar, glue FPGA, and Surge are for development purposes and
have no significance for normal operation.
If the requested version information is not available, the display is always NOT AVAILABLE.
NOTE:
When viewing the software or firmware version information, pressing displays the Versions Menu tree.
To display System Information
1. The default display alternates between the Storage System Name display and the Node World
Wide Name display.
Press any push-button to select the Storage System Menu Tree display.
2. Press to select the Information menu.
3. Press to scroll to Controller Versions.
4. Press to select the Master Version menu or Slave Version menu. If you are operating the master
controller, the Master Version menu is displayed. If you are operating the slave controller, the Slave
Version menu is displayed.
5. Press to display the VCS version.
6. Press to display the Versions Menu tree.
7. Press to scroll to the OCP Firmware.
8. Press to display the OCP Firmware.
9. Press to display the Versions Menu tree.
10. Press to scroll to the OCP Menu.
11. Press to display the OCP Menu.
12. Press to display the Versions Menu tree.
13. Press to scroll to the Address Bus PIC.
14. Press to display the Address Bus PIC.
15. Press to display the Versions Menu tree.
16. Press to scroll to the Battery PIC.
