Determining CRU part numbers
All elements have a 6–3 spare part number on the product label (see Figure 67 ). This nine-character
number appears immediately below the “Replace with HP Spare” statement. The first six characters
(123479) identify the element. The last three characters (–002) define the revision level. The replacement
element revision level must be the same as, or greater than, the number on the element being replaced.
The higher the revision level, the later the revision.
Figure 67 Typical product label
Replacing a disk drive
NOTE:
For the latest information and instructions about disk drives, such as compatibility and installation
instructions, go to the HP website: http://www.hp.com .
To replace a disk drive:
CAUTION:
Remove only one drive at a time and replace it with a drive of equal or greater capacity to avoid data
loss. Allow the system to migrate data onto the replacement drive as indicated by the drive operational
status in HP Command View EVA.
CAUTION:
Remove only one drive or drive blank at a time to avoid overheating the enclosure and to provide an
electro-magnetic EM shield for the enclosure. Replace with another drive or drive blank to ensure proper
air flow and EM shielding.
1. Push in on the disk drive Ejector Button 1 (see Figure 68 ), and pivot the Release Lever 2 to the
full, open position
160 Customer replaceable units
