Table 13 Operational drive status displays
Activity
On-line
Fault
Description
Flashing
(medium speed)
On Off Initial startup.
On On Off The operational drive is not being accessed.
Flashing (high
speed)
Flashing
(medium speed)
On The drive is being located.
Flashing On Off The drive is operational and active.
NOTE:
The drive is configured as part of an array. DO NOT replace an active drive.
Table 14 Non-operational drive status indications
Activity
On-line
Fault
Description
On On On Indicates no connection or the controllers are offline.
Recommended corrective actions:
1. Check power supplies for proper operation.
2. If defective, replace drive.
On Off Flashing Indicates drive error/not active. Recommended
corrective actions:
1. Verify drive loop continuity.
2. Replace drive.
Drive power
The drive voltage backplane sensors (+5.1 VDC and +12.1 VDC) can detect a drive overcurrent condition.
When a drive overcurrent condition exists, the sensor disconnects the voltage from the drive to prevent
writing data to the drive. The drive is disabled until one of the following conditions occurs:
• The drive is replaced, if defective.
• The overcurrent condition no longer exists.
Drive blank
To maintain the proper enclosure air flow, a drive or a drive blank must be installed in each drive bay .
The drive blanks (see Figure 29 ) maintain proper airflow within the disk enclosure.
