Clearing a password
Use the following procedure to remove storage system password protection.
NOTE:
Changing a system password on the controller requires changing the password on any element manager
with access to this system.
1.
Press
to scroll tot he System Password menu.
2.
Press
to select the System Password menu.
3.
Press
to scroll to Clear Password.
4.
Press
to select Clear Password
OR
press
to go to Shutdown Options.
5.
Press
to keep the password
OR
press
to scroll to CLEAR PASSWORD YES.
6.
Press
to clear the password
OR
press
to keep the current password and go to CLEAR PASSWORD NO.
7.
The system will automatically return to the default display.
Setting up a controller pair using the OCP
For information about how to set up a controller pair during initial installation, see
.
HSV controller cabling
All data cables and power cables attach to the rear of the HSV110 controller (see
). Adjacent to
each data connector (see 3, 4, 5, 6, 7, 8, and 9) is a two-colored LED that indicates the link status.
•
When the green LED is on, the link can communicate.
•
When the amber LED is on, the link cannot communicate.
NOTE:
These LEDs do not indicate whether there is communication on the link, only whether the link can
transmit and receive data.
The data connections are the interfaces to the disk drive enclosures or loop switches (depending on your
configuration), the other controller, and the fabric. Fiber optic cables link the controllers to the fabric,
and, if an expansion cabinet is part of the configuration, link the expansion cabinet drive enclosures to
the loop switches in the main cabinet. Copper cables are used between the controllers (mirror port) and
between the controllers and the drive enclosures or loop switches.
