Local Setup
(not connected to the FC
SAN) SystemA SystemB Target system
RCFC links • • Node WWN:
2FF70002AC0000C3 Node WWN:
2FF70002AC000060
• •
Node 0 WWN:
20110002AC000060 Node 0 WWN:
20210002AC0000C3
• • Node 1 WWN:
21210002AC0000C3 Node 1 WWN:
21320002AC000060
Synchronous Mode
Backup system 2 (SystemC) is located far from the primary system and backup system 1, and
therefore must use an IP network.
•
An IP network connects all systems. (The two backup systems use the IP network to share a
standby link for failover and recovery purposes.)
•
Replication between SystemA and SystemC is in asynchronous periodic mode.
Local + Remote Setup
Example backup system 2 Example backup system 1 Example primary system
SystemC SystemB SystemA System name
SystemA SystemA SystemB Target system 1
RCIP links for target system
1 •
Node 2 IP address
10.100.33.96
•
Node 2 IP address
10.100.33.96
•
Node 2 IP address:
10.100.33.195
• • • Node 3 IP address:
10.101.33.195 Node 3 IP address
10.101.33.96 Node 3 IP address
10.101.33.96
SystemB SystemC SystemC Target system 2
RCIP links for target system
2 •
Node 2 IP address:
10.100.33.195
•
Node 2 IP address:
10.100.33.63
•
Node 2 IP address:
10.100.33.63
• • •
Node 3 IP address:
10.101.33.63 Node 3 IP address:
10.101.33.195 Node 3 IP address:
10.101.33.63
Asynchronous periodic —>
SystemA Asynchronous periodic —>
SystemC Mode
Verifying Connectivity between Systems
Verify the connectivity for each Remote Copy pair you are configuring.
•
RCIP Remote Copy pairs:
# controlport rcip ping
•
RCFC Remote Copy pairs:
# showrctransport -rcfc
For more information, see “Verifying the Servers Are Connected” (page 35) .
58 Setting Up Synchronous Long Distance Remote Copy
