Command line 96
Item Description
->show role domain
Displays the authentication order for the domain user role
->show role *
Displays the authentication order for all user roles
server-port-map-range
Manage ranges of shared server downlink port mapping configurations.
Supported actions: add, help, remove
Item Description
add server-port-
map-range
Add a new server port network mapping range, and allow server ports to be shared
among multiple VC Ethernet networks.
Syntax
add server-port-map-range UplinkSet=
Set Name> VLANIDs=
[MatchUplinkSet=]
Parameters
ConnectionId
(required)
The ID of an existing Ethernet connection associated with a profile and a server
port. The format of the ConnectionID is .
Properties
Uplinkset (required) The name of the shared uplink set to use with the server port mapping
VLANIDs (required) The VLAN IDs to use for the mapping. The format is a comma-separated list of VLAN
ID ranges, where a range is either a single VLAN ID or a hyphen-separated pair of
VLAN IDs that identify a range of VLAN IDs. Valid VLAN ID values include 1 to
4094.
MatchUplinkSet
(optional)
Requires that the VLANs used for mappings match the VLAN IDs specified on the
identified Uplink Set. If set to false, the command will not set the profile connection
associated uplink set attribute (but will use the uplink set VLAN IDs from the uplink
set). If there are already server port map entries for the specified profile connection,
then either the uplink set must match or the port map entries must not have the
associated uplink set attribute specified. The default value of this attribute is "false".
Examples
->add server-port-map-range MyProfile:1
UplinkSet=MyUplinkSet1 VLanIds=101-124,214
Adds multiple networks to a server-port-map
->add server-port-map-range MyProfile:2
UplinkSet=MyUplinkSet2 VLanIds=1-20 MatchUplinkSet=true
Adds multiple networks to a server-port-map and locks VLANs to an uplink set
Item Description
remove server-port-
map-range
Remove one or more server port network mappings.
Syntax
remove server-port-map-range VLANIds=
Range List>
Parameters
ConnectionId
(required)
The ID of an existing Ethernet connection associated with a profile and a server
port. The format of the Connection ID is .
VLANIDs (required) The list of VLAN IDs to be removed from the mapping. The format is a
comma-separated list of VLAN ID ranges, where a range is either a single VLAN ID
