Command line 33
enet-vlan
Manage Ethernet VLAN configuration settings.
Supported actions: help, set, show
Item
Description
set enet-vlan
Modify general Ethernet VLAN configuration settings.
Syntax
set enet-vlan [-quiet][SharedServerVLanId=
[PrefSpeedType=
[MaxSpeedType=
[VlanCapacity=
Option
quiet
This option suppresses user confirmation prompt, and is typically used in
automated scripting scenarios.
Properties
SharedServerVLanId
(optional)
Enables or disables the option to force server ports connected to multiple VC
Ethernet networks to use the same VLAN mappings as those used by
corresponding shared uplink sets. Valid values are "true" and "false".
Setting the value to "true" restricts the server network connections to be selected
from a single shared uplink, and the VLAN ID cannot be modified.
Setting the value to "false" enables you to select any VC Ethernet network for the
server Ethernet connections, and VLAN ID mappings can be modified to ensure
uniqueness.
PrefSpeedType
(optional)
The default connection speed for any Ethernet connection using multiple
networks. Valid values are "Auto" and "Custom". "Custom" enables you to
configure the preferred speed. The default value is "Auto".
PrefSpeed (required if
PrefSpeedType is
Custom)
The default connection speed for any Ethernet connection using multiple
networks. Valid values range from 100Mb to 10Gb in 100Mb increments.
MaxSpeedType
(optional)
The maximum connection speed for any Ethernet connection using multiple
networks. Valid values are "Unrestricted" and "Custom". "Custom" enables you
to configure the preferred speed. The default value is "Unrestricted".
MaxSpeed (required if
MaxSpeedType is
Custom)
The maximum connection speed for any Ethernet connection using multiple
networks. Valid values range from 100Mb to 10Gb in 100Mb increments.
VlanCapacity
(optional)
The VLAN capacity mode. Valid values are "Legacy" and "Expanded". The
default value is "Legacy".
"Legacy" mode allows up to 320 VLANs per module and 28 VLANs per server
connection.
"Expanded" mode allows up to 1000 VLANs per domain and 162 VLANs per
physical server port.
Examples
->set enet-vlan SharedServerVLanId=true
Enables SharedServerVLanId
->set enet-vlan PrefSpeedType=Custom PrefSpeed=500
MaxSpeedType=Custom MaxSpeed=2500
Sets the preferred connection speed for all connections using multiple networks to
500Mb, and the maximum connection speed to 2.5Gb
->set enet-vlan VlanCapacity=Expanded
Sets the VLAN capacity mode to Expanded to allow for larger network
configurations
